Woodpecker Implanter Plus Implant Motor with 20:1 Fiber Optic Handpiece

Woodpecker Implanter Plus Implant Motor with 20:1 Fiber Optic Handpiece

Features:

• Outstanding quality makes it your solid choice
• Intuitive user interface
• Motor with precision and strength
• Strong and stable contra-angle
• Color touch screen with glass surface
• Mute peristalic pump
• Implanter Plus is the highest configuration implant motor from Woodpecker. Implanter Plus your favorite assistant of high-precision dental implanting treatment.

Motor specifications:
Model: SPM58L, SPM58NL, SPM58, SPM58LS
Rotating speed range: 300-40,000 rpm
Torque range: 5-80 Ncm(ratio: 20:1)
Input voltage: DC29V
Dimension: Maximum diameter 21.5 mm, Length 110 mm
Tail cord length: 1.8m

Foot pedal controller specifications:
Model: MF4
Tail cord length: 2.8m

Primary technical parameters:
Device for intermittent operation: 3 min ON,10 min OFF
Power supply voltage: 200-240V~
Power supply frequency: 50/60Hz
Software version: Implant-V1
Input power: 150VA
Fuses: 2×T1.6AL 250V
Applied parts: Contra-angle handpiece
Maximum Temperature: 41.8℃
Maximum water volume: 135ml/min
Dimension: 276mm*267mm*110mm
