Ray Foster Model MTD1C Dry Model Trimmer w/ Cyclone Dust Collector
RAY-MTD1CRay Foster Model MTD1C Dry Model Trimmer w/ Cyclone Dust Collector
Regular price
$2,099.00
Sale price
$2,099.00
Regular price
$2,499.00
Unit price
per
Description
Model Trimmer MTD1C Produce high quality, precise models without water and can be placed in any space available location, as there is no need to connect to your water supply and it does not require a drain.
MTD1 Features:
MTD1 Specifications:
Model Trimmer CD1C is a powerful and efficient dust collector for use in the dental laboratory, designed for trouble-free performance and heavy-duty operation. Quiet, portable and compact, the dust collector is ideal for under-the-counter operation.
CDC1 Specifications
Includes: MTD1 Dry Model Trimmer & Cyclone Dust Collector
Ā
MTD1 Features:
- Rigid cutting surface gives a flat, smooth finish
- Simplified mechanics (no pulleys or belts) results in a smooth running, quiet machine
- Power output connection for automatic on/off of dust collector View
- Uses fast cutting 10ā diameter PSA abrasive discs
- Heavy-duty, capacitor-start, 1/3 HP motor
- Adjustable work table
- Six foot vacuum hose and three additional abrasive discs included
- Proven Ray Foster quality and durability
MTD1 Specifications:
- 14ā high, 14ā wide, 15ā deep
- 115 volt, 60 Hz standard
- Wheel size 10ā diameter
- 1-1/2ā O.D. suction connection
- 230 volt 50/60 Hz optional for export
- Net weight 35 lbs, shipping weight 40 lbs, shipping dimensions: 20 X 16 X 16 inches
Model Trimmer CD1C is a powerful and efficient dust collector for use in the dental laboratory, designed for trouble-free performance and heavy-duty operation. Quiet, portable and compact, the dust collector is ideal for under-the-counter operation.
- Very quiet 59 dB noise level
- One HP motor, 112 cubic feet per minute (CFM) suction power
- Easy to change, economical disposable paper primary filter. Retains 3 micron and larger particles
- Permanent cloth secondary filter for retention of finer dust particles, insuring long motor life
- Two station capability
- Includes one 6ā long X 2-1/2ā ID vacuum hose and four (4) extra disposable paper dust bags
- Optional remote foot switch
- Easily adaptable to 1-1/2ā³, 2-1/2ā³ or 3ā³ I.D. hose for increased flexibility
CDC1 Specifications
- Unit size 12ā x 12ā x 16.5ā high
- 115 volt, 60 Hz standard
- 230 volt, 50/60 Hz optional for export
- 35 lbs. net weight, 42 lbs. shipping weight, dimensions: 16 X 16 X 26 inches
Includes: MTD1 Dry Model Trimmer & Cyclone Dust Collector
