Sterilization Times
Cycle 1 – 6 minutes for unwrapped instruments
Cycle 2 – 8 minutes for hand pieces and medical drills
Cycle 3 – 12 minutes for wrapped instruments
Unit Size (OD) | 22.5″ W x 22.5″ D x 19.5″ H 572 mm x 572 mm x 495 mm |
Chamber Size (ID) | 11”W x 17.75”D x 11.75”H, 279mm x 433mm x 299mm |
Weight | 75 lbs (34 Kg) |
Instrument Tray | 9”W x 15”D x 1”H, 229mm x 381mm x 28mm |
Electrical | 110-120V, 60Hz, 1400 Watts warm up, 300 Watts operating 220-240V, 50Hz, 1400 Watts warm up, 300 Watts operating |
Sterilization Temperature | 375º Fahrenheit (190º Celsius) |
Warranty | Three years (parts and labor) |
Safety | Meets Requirements of U.S. Electrical Safety Standards. |
Sterilization Times
Cycle 1 – 6 minutes for unwrapped instruments
Cycle 2 – 8 minutes for hand pieces and medical drills
Cycle 3 – 12 minutes for wrapped instruments
